一、10K主要连接及重量
|
尺寸
|
inch
|
1/2″
|
3/4″
|
1″
|
1-1/2″
|
2″
|
2-1/2″
|
3″
|
4″
|
5″
|
6″
|
8″
|
10″
|
|
DN
|
15
|
20
|
25
|
4
|
50
|
65
|
80
|
100
|
125
|
150
|
200
|
250
|
|
L
|
mm
|
108
|
117
|
127
|
165
|
178
|
190
|
203
|
229
|
356
|
394
|
457
|
533
|
|
H
|
mm
|
59
|
63
|
75
|
97
|
107
|
142
|
152
|
178
|
252
|
272
|
342
|
345
|
|
W
|
mm
|
130
|
130
|
160
|
230
|
230
|
400
|
400
|
700
|
1100
|
1100
|
1500
|
1500
|
|
重量
|
㎏
|
2.3
|
3.0
|
4.5
|
7.0
|
9.5
|
15.0
|
19.0
|
33.0
|
58.0
|
93.0
|
160.0
|
200.0
|
二、20K主要连接尺寸及重量
|
尺寸
|
inch
|
1/2
|
3/4
|
1
|
1-1/2
|
2
|
2-1/2
|
3
|
4
|
5
|
6
|
8
|
10
|
|
DN
|
15
|
20
|
25
|
4
|
50
|
65
|
80
|
100
|
125
|
150
|
200
|
250
|
|
L
|
mm
|
140
|
152
|
165
|
190
|
216
|
241
|
283
|
305
|
381
|
403
|
502
|
568
|
|
H
|
mm
|
59
|
63
|
75
|
97
|
107
|
142
|
152
|
178
|
252
|
272
|
342
|
345
|
|
W
|
mm
|
130
|
130
|
160
|
230
|
230
|
400
|
400
|
700
|
1100
|
1100
|
1500
|
1500
|
|
重量
|
㎏
|
2.5
|
3.5
|
5.5
|
10.5
|
14.5
|
23.5
|
30.0
|
55.0
|
81.0
|
118.0
|
200.0
|
250.0
|
|
